Designed for industrial usage, iTegno 39XX enables
remote connectivity with different interfaces (namely RS-232 and
RJ-45), option of external or internal antenna, and protocols such
as TCP/IP and UDP/IP in a compact form factor. Built to withstand
harsh and demanding environmental conditions, iTegno 39XX meets
specifications IEC60068 for environmental testing and EN60529 for
IP code protection, and extended temperatures of -40°C to +85°C.
The versatile modem offers options of embedding other RF technology
like ZigBee in the same compact form factor.
Key features:
-
Quad band GSM for global
coverage
-
Full RS-232 Connectivity
-
Interface of RS-232 or RJ-45 (Customised pin
configuration)
-
Embedded / External Antenna
-
Extended Temperature Range
-
Reliability Enhanced
-
EN60529 for IP54 rating
- SIZE: 90mm x 50mm x 20mm
- WEIGHT: <60g
- RS-232 or RJ-45 SERIAL INTERFACE
- GPRS CLASS 10, CODING SCHEME CS1 TO CS4
- MAX PACKET SWITCH (GPRS) DATA TRANSMISSION SPEED: 85.6
kbps
- MAX CIRCUIT SWITCHED (GSM CSD) DATA TRANSMISSION: 14.4kbps
- AUTOMATIC FAX GROUP (Class 1 and Class 2)
- QUAD BAND GSM:
EGSM900 / DCS1800 / GSM850 / PCS1900
- IP54 RATING
- COMPLIANCE: EN60950 / IEC60068 / EN50385
- SMS SERVERS
- PC'S, LAPTOPS AND SERVERS
- REMOTE TELEMETRY
- SECURITY SYSTEMS
- POINT OF SALE (EPOS) APPLICATIONS
- AUTOMATED METER READINGS
- FLEET MANAGEMENT
| MODEL NUMBER |
DESCRIPTION |
INTERFACE |
| iTegno-3932 |
Standalone TCP/IP, GPRS 850/900/1800/1900 modem with
serial DB9 interface. Powered via RS-232 connection.
External antenna must be ordered separately.
|
Serial RS-232
|
| iTegno-3945 |
Standalone TCP/IP, GPRS
850/900/1800/1900 modem with serial RJ-45
interface, powered via RJ-45 connection. External antenna
must be ordered separately.
|
Serial RJ-45
|
