iTegno's 3800 range of external standalone GSM modems
provide wireless data communication and can be integrated
seamlessly with virtually any application.
Powered by USB, from either your laptop or PC, iTegno 3800 does
not require batteries or bulky power supplies. Users can truly
enjoy wireless access to the internet, can make voice calls or send
and receive e-mails, faxes and SMS messages from anywhere at
anytime.
iTegno 3800 is an enhanced GSM quad-band version of the
popular 3000 and 3900 modems and is compatible with all
laptops and PCs installed with Win 98SE, 2000, ME or XP. Drivers
for Linux and Mac Os are available for development purposes.
The iTegno 3800 modem is bundled with the intuitive
and powerful iSMS application for contacts and SMS management. The
iSMS application offer users ease of importing their contact
databases from excel with powerful contacts management and SMS
broadcasting abilities. Rated at over 12,000 SMS messages in a
single day, iSMS Application also supports concurrent operation of
multiple modems using a single PC. Designed with USB and Serial
Port interface options, it offers SMS broadcasting capabilities in
prolonged usage to a range of computing devices from PC to
servers.
Key features:
-
Quad band GSM for global
coverage
-
Small size : 94.2 x 66.0 x 14.5 mm Weight: 58
grams
-
Bundled with iSMS contacts management and SMS
broadcasting application
-
Send over 12,000 SMSes in a day
- SIZE: 93mm x 64mm x 12mm
- WEIGHT: 58g
- USB 1.1 INTERFACE
- AVAILABLE WITH EMBEDDED INTERNAL ANTENNA
- GPRS CLASS 10, CODING SCHEME CS1 TO CS4
- MAX PACKET SWITCH (GPRS) DATA TRANSMISSION SPEED: 85.6
kbps
- MAX CIRCUIT SWITCHED (GSM CSD) DATA TRANSMISSION: 14.4kbps
- AUTOMATIC FAX GROUP (Class 1 and Class 2)
- VOICE SUPPORT
- SUPPLIED WITH iTegno MOBILE OFFICE SUITE
- QUAD-BAND GSM:
EGSM900 / DCS1800 / GSM850 / PCS1900
5
TECHNICAL SPECIFICATIONS
5.1
General Features
Feature
Specification
Standard
•
Quad-band: GSM 850/ EGSM900/ DCS1800/ PCS1900
•
Compliant to ETSI GSM Phase 2+
Data
•
Asynchronous, transparent and non-transparent
•
Maximum speed: up to 14.4kbps
•
Point-to-point (MO/MT)
•
Text /PDU
•
Cell Broadcast
GPRS
•
Terminal Class B
•
Multislot Class 10
•
Data rates: Downlink - up to 85.6 kbps
Uplink - up to 42.8 kbps
Fax
•
Group 3
•
Fax 2.0
•
Max speed (kbps): up to 9.6kbps
Host Protocol
•
AT Commands compliant to GSM 07.07, 07.05
•
iWOW Proprietary AT Commands
Firmware Stack
•
TCP/IP and UDP/IP
•
MMS
5.2
Mechanical Characteristics
Feature
Specification
Dimension (mm)
94.2 x 66.0 x 14.5
Weight (g)
58
Lead-free
Yes
Cooling Mechanism
Internal Dual Flow Air Convection
Power Supply Interface
PC powered via USB host (No external power supply)
Communication Port
USB Receptacle mini-B
USB 1.1
VBUS, D+, D-, GND
Baud rates from 110 to 115200 bps
- SMS SERVERS
- PC'S, LAPTOPS AND SERVERS
- REMOTE TELEMETRY
| MODEL NUMBER |
DESCRIPTION |
INTERFACE |
| iTegno-3800 |
Standalone TCP/IP, GSM/GPRS 850/900/1800/1900 modem
with USB interface and internal antenna. Powered by host
device through the USB connector. |
USB |
| iTegno-3832 |
Standalone TCP/IP, GSM/GPRS
850/900/1800/1900 modem with serial DB9 interface.
Supplied with 900/1800MHZ external antenna (MMCX connector) and PSU
(European 2-pin).
|
Serial RS-232
|
| iTegno-3832-NA |
Standalone TCP/IP, GSM/GPRS 850/900/1800/1900 modem
with serial DB9 interface. Supplied with PSU (European 2-pin).
External antenna must be ordered separately.
|
Serial RS-232
|
| iTegno-3845 |
Standalone TCP/IP, GSM/GPRS
850/900/1800/1900 modem with serial RJ45 interface,
powered through PIN 1 of RJ45 connector. Supplied with 900/1800MHZ
external antenna (MMCX connector).
|
Serial RJ45
|
| iTegno-3845-NA |
Standalone TCP/IP, GSM/GPRS
850/900/1800/1900 modem with serial RJ45 interface,
powered through PIN 1 of RJ45 connector. External antenna
must be ordered separately.
|
Serial RJ45
|
